The YC-200 S plus from NIDEK is an ophthalmic laser system combining YAG and SLT technologies, designed for precise treatments such as capsulotomy, peripheral iridotomy and selective laser trabeculoplasty. With improved optics, an intuitive interface and features such as SLT-NAVI and a motorised joystick, it offers a smooth and comfortable surgical experience. Its ergonomic design and optimised energy performance ensure reliable results while reducing practitioner fatigue. Ideal for glaucoma specialists and anterior segment surgery.

Features:
- Refined laser delivery with lower energy
- SLT mode
- Clear and sharp field of view
- Precise aiming beam
- Optimized operating distance
- Unique joystick
- Coaxial illumination for better visualization

The SLT mode of the YC-200 S plus is optimised for reduced energy density on the cornea, thanks to a cone angle of 5.5°, reducing the risk of damage during repeated treatments. The SLT-NAVI system guides the surgeon through the procedure with an intuitive display of the number of impacts and treatment progress.

The optics of the YC-200 S plus offer superior resolution and contrast, with extended depth of field for clear visualisation of ocular structures. LED lighting provides natural, bright vision, reducing aberrations. The 360° rotating targeting beam avoids corneal opacities and achieves optimal focus.

The motorised joystick with integrated S-switch allows treatment parameters to be changed without leaving the eyepieces, improving surgeon comfort. The optimised working distance facilitates contact lens handling and reduces fatigue during prolonged procedures.

The control box with colour touch screen and SD card allows for quick configuration, software updates and recording of treatment parameters. The graphical interface simplifies navigation and adjustment of settings.

In addition to YAG and SLT modes, the YC-200 S plus can be combined with a retinal photocoagulation laser (GYC-500), expanding its capabilities for posterior segment treatments.

Specifications:
YAG mode
- Laser source : Q-switched Nd:YAG
- Wavelength : 1,064 nm
- Pulse width : 3 ns
- Pulse repetition rate : 3 Hz (single) / 1.5 Hz (burst)
- Output energy : 0.3 to 10.0 mJ / pulse
- Burst mode : 1, 2 and 3 pulses per trigger
- Spot size : 8 μm
- Cone angle : 16º
- Focus shift : 0 to ±500 μm
- Aiming beam : 635 nm / OFF, max. 25 μW

SLT mode
- Laser source : Q-switched, frequency doubled Nd:YAG
- Wavelength : 532 nm
- Pulse width : 3 ns
- Pulse repetition rate : 3 Hz
- Output energy : 0.3 to 3.0 mJ / pulse
- Spot size : 400 μm
- Cone angle : 5.5°
- Aiming beam : 635 nm / OFF, max. 0.3 mW

Slit lamp
- Illumination : LED lamp
- Magnification (field of view) : 5x (40.7 mm), 8x (25.7 mm), 12.5x (16.1 mm), 20x (10.1 mm), 32x (6.4 mm)
- Power supply : 100 to 240 V AC, 50/60 Hz- Power consumption : 100 VA
- Dimensions/mass : 346 (W) x 422 (D) x 577 (H) mm / 18 kg
                               13.6 (W) x 16.6 (D) x 22.7 (H)" / 39.7 lbs.
- Optional accessories : Foot switch, Stand for control box, Safety goggles, Green laser photocoagulator combination delivery unit (NIDEK GYC-500)

Package includes:
- Nidek YC-200 S plus Main body
- Head rest
- Control box,
- Connector box
- Remote connector plug
- Keycard
- Power cord
- Chinrest paper
- Head belt
- Grips
- Focusing rod
- Attachment plates
- Arm rest
- Cap
- Dust cover
- DANGER label
- Operator's manual
- Foot switch
- Illumination tower (tilting / with the base fixed / split mirror illumination)
- Stand for CB
- Safety goggles
