Carestream CS 3700 delivers a high-performance scanning experience that takes you in any direction you want to go. Prestigious design―by Studio F. A. Porsche. Turbo-speed scanning. Patient- and practitioner-centric workflows. Smart-shade matching. Touchscreen capabilities. With the CS 3700, compromise is a thing of the past.

CS ScanFlow
CS ScanFlow  integrates with your CS 3700 to provide you with unlimited workflow capacity, faster scanning, expanded processing options, one-click export and touchscreen capabilities. With convenient access to every post-scan option from a single screen, the possibilities are endless.

Experience comfort and functionality
The CS 3700 is designed to provide you with both tremendous comfort and superior functionality

- Turbo scan speed is proven to scan in vitro single arches in 30 seconds when the recommended PC configuration is used.
- An ergonomically optimal grip channel provides balanced scanner control
- An optional wrist strap connects the user to the scanner and prevents damage from dropping
- User-friendly CS ScanFlow software lets you pursue any indication from a single scan
- Enjoy an average of 60% faster processing speeds1
- Clean mesh details, prepare the base for printing, and send digital models to a lab or third-party in just one click

Drive better outcomes
With next-level technology, exceptional versatility and improved scanning views, the CS 3700:

- Smart-shade matching automatically detects the enamel color of the scan area to identify the ideal match for optimum restorative outcomes
- Features hybrid scan capabilities, enabling you to merge a partial impression with a digital in vivo scan into a single file
- Provides a clearer view of the live scan, thanks to more scan space real estate

Features:
- Turbo-Speed Scanning
- Prestigious Design
- Patient and Practitioner Centered Workflows
- Smart-Shade Matching
- Touchscreen Capabilities

Specifications:
- Resolution : Still image 1024 x 768 pixels, Video: 640 x 480 pixels
- Weight : 316 g (excluding cable and power box)
- Image Capture Method : Yes, full color HD 3D
- Illumination : LED: Amber, Blue, Green
- Computer Connection : USB 2.0 High Speed
- Acquisition Method : Active triangulation with Smart-shade matching via BRDF (Bidirectional Reflectance Distribution Function) technology
- Orthodontic Analysis : Additional modules available, CS Model, CS Model+, and CS FaceScan with CS 3D Imaging software for the merge of the face scan, CBCT and scanned dataset for comprehensive orthodontic treatment planning
- CAD/CAM Systems Available : Direct integration with exocad and exocad Chairside CAD, also available for use with open architecture solutions
- True Color Image Available : Yes, as both 2D and 3D image plus multi-layer shade information
- Lab Integration : Yes, direct integration from acquisition software via CS Connect with complimentary CS MeshViewer for full color viewing
- Fields of View : 13 x 13 mm, 13 x 7 mm (posterior tip)
- Scan Speed : 30 single arch scans (per in vitro testing), 10 fps
